Be Your Good Assistant
Integrated Intelligent ISP Algorithm, Cope
Complicated Lights with Ease
Invariable quality in changeable lights
Product Parameters
General Parameters
-10℃~60℃
-20℃~60℃
10%～90%
Max. 15W
DC 12V/2A (in different standards)
IP65, for outdoor use
Display
7-inch TN touch screen
1024 * 600
RGB Camera
1/2.7" 2MP COMS HD WDR camera
120dB
1932 * 1092
90°
Electronic rolling shutter
Auto
Auto
Auto
f=3.5mm, Aperture F2.0
Infrared Camera
1/2.7" 2MP CMOS HD WDR camera
120dB
1932 * 1092
90°
Electronic rolling shutter
Auto
Auto
Auto
f=3.5mm, Aperture F2.0
System Parameters
Linux
Dual-core ARM Cortex-A7@ 900MHz
512MB RAM, 8GB ROM
Interfaces
RS232, RS485, Wiegand26/34 Output/Input, Relay Output, TTL Output, USB Type-A, Alarm Input, Exit Door Input, QR code access, Card reader
Communication Mode
RJ45, Wi-Fi, 4G (optional)
Functions
Up to 99.99%
50-thousand face database (Max. 100-thousand)
Standard EM&MIFARE card
1 million pieces of recognition records
Live detection: 0.3-1.5m; Non-live: 0.3-3m
Supports
Supports
Cloud, LAN
